Ubiquiti Networks Rocket 5AC Lite (R5AC-LITE)

Description Ubiquiti Networks Rocket 5AC Lite (R5AC-LITE) Ubiquiti Networks Rocket 5AC Lite (R5AC-LITE) is a high-performance, cost-effective airMAX® ac BaseStation designed for outdoor Point-to-Point (PtP) and Point-to-MultiPoint (PtMP) deployments. It operates in the 5 GHz frequency band and is optimized for long-range wireless bridging and backhaul applications. Hardware Specifications Processor: Atheros MIPS 74Kc, 720 MHz Memory: 128 MB DDR2 SDRAM, 16 MB NOR Flash Networking Interface: (1) 10/100/1000 Mbps RJ45 Gigabit Ethernet port RF Connectors: (2) RP-SMA (Waterproof) Enclosure: Outdoor UV-stabilized plastic Dimensions: 162 x 84 x 37 mm (6.38 x 3.31 x 1.46″) Weight: 250 g (8.81 oz) Power Supply: 24V, 0.5A Gigabit PoE Adapter (Included) Power Method: Passive PoE (Pairs 4, 5 ; 7, 8 Return) Max. Power Consumption: 8.5W Operating Temperature: -40 to 80° C (-40 to 176° F) Operating Humidity: 5 to 95% Noncondensing ESD/EMP Protection: ±24 kV Air / Contact Shock and Vibration: ETSI300-019-1.4 Certifications: CE, FCC, IC, RoHS Complian  Wireless Specifications Operating Frequency: Worldwide: 5150 – 5875 MHz USA: 5725 – 5850 MHz Channel Sizes: PtP Mode: 10/20/30/40/50/60/80 MHz PtMP Mode: 10/20/30/40 MHz Modulation: 256QAM Transmit Power: Up to 27 dBm Sensitivity: -96 to -65 dBm Wireless LAN Standard: IEEE 802.11ac Wireless Security: WPA2 AES Only Software Features Operating Modes: Access Point, Station Services: Web Server, SNMP, SSH Server, Telnet, Ping Watchdog, DHCP, NAT, Bridging, Routing Utilities: Antenna Alignment Tool, Discovery Utility, Site Survey, Ping, Traceroute, Speed Test QoS: Supports Packet Level Classification WMM and User Customer Level: High/Medium/Low Distance Adjustment: Dynamic Ack and Ackless Mode Power Adjustment: Software Adjustable via UI or CLI Statistical Reporting: Up Time, Packet Errors, Data Rates, Wireless Distance, Ethernet Link Rate Other Features: Remote Reset Support, Software Enabled/Disabled, VLAN Support, Traffic Shaping with Burst Support, Frequency Band Offset  Performance Maximum Throughput: 500 Mbps Range: Up to 25 km (15.5 miles), depending on antenna and environmental conditions Integration and Compatibility Compatible Antennas: PtP Backhaul: RocketDish™ ac PtMP Links: airMAX ac Sector Enclosure Form Factor: Pole Mount Indoor/Outdoor: Outdoor For optimal performance, it’s recommended to pair the Rocket 5AC Lite with appropriate airMAX ac antennas, such as the RocketDish™ ac for PtP backhaul or the airMAX ac Sector for PtMP links. This device is ideal for deployments requiring high throughput and long-range capabilities in challenging outdoor environments.
